CPU and Flexible IO

High performance 32bit RISC-V processor Core with DSP instruction

RISC-V typical speed: 125MHz

Program memory: internal 1M bit flash

Internal 113KB RAM for data and program

Flexible GPIO pins with Programmable pull-up and pull-down resistors;

Support GPIO wakeup or interrupt;

Bluetooth Radio

Compliant to Bluetooth 6.0（QDID: Q342943）;

TX output power +9dBm in MAX;

X Sensitivity with -90.5 @ Basic Rate;

RX Sensitivity with -94 @EDR;

Audio Interface

Audio codec with 16bit mono DAC and 16bit mono ADC;

Support flexible audio EQ adjust;

Support Sample rate 8, 11.025, 12, 16, 22.05, 32, 44.1 and 48KHz;

Mono MIC amplifier input;

High performance mono audio ADC with 94dB SNR;

High performance mono audio DAC with 102dB SNR, with headphone amplifier output;

Package

QFN20 3*3;

Temperature

Operating temperature: -40℃ to +85℃;
Storage temperature: -65℃ to +150℃;
