AB212B DataSheet.pdf

CPU and Flexible IO

High performance 32bit RISC-V processor Core with DSP instruction

RISC-V typical speed: 125MHz

Program memory: internal 2M bit flash

Internal 163KB RAM for data and program

Flexible GPIO pins with Programmable pull-up and pull-down resistors;

Support GPIO wakeup or interrupt;

Peripheral and Interfaces

Support Low power Touch Key;

Support Low power enter ear detect;

Three 32-bit timers;

Three multi-function 32-bit timers, support Capture and PWM mode;

WatchDog;

Three full-duplex UART;

Two SPI;

IR controller;

SD Card Host controller;

Full speed USB 2.0 HOST/DEVICE controller;

Sixteen Channels 10-bit SARADC;

Integrate IRTC;

Build in PMU, such as charger/buck/LDO;

Package

QFN32;

Temperature

Operating temperature: -40℃ to +85℃;
Storage temperature: -65℃ to +150℃;
