CPU and Flexible IO
RISC-V 32bit High performance CPU with DSP instruction;

Program memory: internal 4M bit flash;

Flexible GPIO pins with Programmable pull-up and pull-down resistors;

Support GPIO wakeup or interrupt;

Bluetooth Radio
Compliant to Bluetooth 5.4(QDID: 215269);

TX output power +6dBm in typical;

RX Sensitivity with -90.5dBm @EDR;

Audio Interface
Audio codec with 16bit stereo DAC and 16bit mono ADC;

Support flexible audio EQ adjust;

Support Sample rate 8, 11.025, 12, 16, 22.05, 32, 44.1 and 48KHz;

2 channel Analog MUX;

One channel MIC amplifier input;

High performance mono audio ADC with 90dB SNR;

High performance audio DAC with 96dB SNR, with headphone amplifier output;

Package
SOP16;

Temperature

Operating temperature: -40℃ to +85℃;
Storage temperature: -65℃ to +150℃;

Product Applications

簡易帶卡帶U音箱；
